Automation technology - Voltage and Power Supply
Filter products
Connector type
The connector type can be used to distinguish our products for installation in a device housing from cable parts. The connector type describes the difference between connectors that are mounted on enclosures and connectors that are mounted on cables.
Gender
A connector consists of the male part (pin) and the female part (socket). Depending on the design, the male or female part is either permanently installed or are located at the end of a cable.
Number of contacts
This indicates the number of contacts the connector has.
Version
The choice of version allows the definition of certain technical specifications – for example the type of cable outlet or the size.
Locking Type
The locking system describes how the pin and socket elements are joined.
Rated voltage
The rated voltage is the electrical voltage assigned to the connector.
Rated current
The rated current is the electrical current that is assigned to the connector.
Degree of protection
The degrees of protection according to IEC60529 apply to various articles and provide information on protection against the intrusion of water and solids such as dust.
Shielded Option
Electromagnetic compatibility (EMC) means that a connector is shielded or shieldable. This is required when it is necessary to protect the signals or data conducted by the connector, as well as to protect external devices, from disturbance due to electromagnetic effects.
Material of housing
Depending on the area of application or requirements, connectors are made of different materials. We offer metal and plastic housings for our items as the housing material.
Coding
The connector elements, pin and socket, must be brought into form-fitting alignment with one another (coding) before locking. This prevents mismating.
Termination
The termination type determines how cables, single wires or PCBs can be joined with the connector.
Approval
Our articles have various approvals which can be preselected here. can be preselected here.
Cable type
By selecting the cable type, a preselection for the respective application can be carried out.
Cable Jacket Type
The material of the cable jacket. PUR, TPE, TMPU or TPE-U cables each have different technical properties.
Cable color
The color of the cable jacket.
Cable length
Our items with molded or pre-assembled cables have different cable lengths. It describes the length of the cable from the end of the connector. If the desired cable length is not included, please contact our sales department.
Locking material
Depending on the technical requirements or performance data of the connector, the locking mechanism is made of plastic or metal.
Show products
  1. Products
  2. Automation technology - Voltage and Power Supply
  3. M12-K

M12-K coded connectors - Automation technology

Series PDF (2 MB)
Accessory as PDF (578 KB)

Connectors of the 824 series with screw locking according to DIN EN 61076-2-111 are K-coded for AC applications. They have 4+PE contacts with a rated current of 12A at 630VAC. These connectors are available in a terminated version, both straight and right-angled. Flange connectors are available with stranded wires.

M12-Power (S, K, T, L) | Connectors for power applications
Watch now on YouTube
Automation Technology - Voltage and Power Supply--Male cable connector_814_1_KS_K-Kod
99 0699 29 05
M12 Male cable connector, Contacts: 4+PE, 8.0-13.0 mm, unshielded, screw clamp, IP67, UL
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Female cable connector_824_2_KD_K
99 0700 29 05
M12 Female cable connector, Contacts: 4+PE, 8.0-13.0 mm, unshielded, screw clamp, IP67, UL
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Male panel mount connector_814_3_FS_K
09 0701 700 05
M12 Male panel mount connector, Contacts: 4+PE, unshielded, single wires, IP68, UL, M16x1.5
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Male panel mount connector_814_3_FS_K
09 0701 400 05
M12 Male panel mount connector, Contacts: 4+PE, unshielded, single wires, IP68, UL, M16x1.5
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Male panel mount connector_824_3_FS_K_vv
09 0701 300 05
M12 Male panel mount connector, Contacts: 4+PE, unshielded, single wires, IP68, UL, M16x1.5, screwable from the front
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Male panel mount connector_824_3_FS_K_vv
09 0701 800 05
M12 Male panel mount connector, Contacts: 4+PE, unshielded, single wires, IP68, UL, M16x1.5, screwable from the front
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Female panel mount connector_814_4_FD_K
09 0702 700 05
M12 Female panel mount connector, Contacts: 4+PE, unshielded, single wires, IP68, UL, M16x1.5
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Female panel mount connector_814_4_FD_K
09 0702 400 05
M12 Female panel mount connector, Contacts: 4+PE, unshielded, single wires, IP68, M16x1.5
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Female panel mount connector_824_4_FD_K_vv
09 0702 800 05
M12 Female panel mount connector, Contacts: 4+PE, unshielded, single wires, IP68, UL, M16x1.5, screwable from the front
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Female panel mount connector_824_4_FD_K_vv
09 0702 300 05
M12 Female panel mount connector, Contacts: 4+PE, unshielded, single wires, IP68, UL, M16x1.5, screwable from the front
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Male angled connector_814_1_WS_K
99 0699 58 05
M12 Male angled connector, Contacts: 4+PE, 8.0-13.0 mm, unshielded, screw clamp, IP67, UL
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
Automation Technology - Voltage and Power Supply--Female angled connector_824_2_WD_K
99 0700 58 05
M12 Female angled connector, Contacts: 4+PE, 8.0-13.0 mm, unshielded, screw clamp, IP67, UL
M12-K, series 824, Automation Technology - Voltage and Power Supply
Details
